3 Phase Natural Gas Generator, 400kW 500kVA, 50Hz, 12 Cylinder

Name: 3 Phase Natural Gas Generator, 400kW 500kVA, 50Hz, 12 Cylinder
SKU: GGS-240313-GGS-03
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Introducing our premium 3 Phase Natural Gas Generator, designed to meet your power demands with a rated power of 400kW (500kVA). Equipped with a robust 12 Cylinder Cummins engine, this generator operates at 50Hz, ensuring reliable performance. With a current rating of 720A and a brushless, self-excited alternator, it guarantees stable and efficient power generation for your applications. Trust in our generator for dependable electricity supply.

Request a quote

Detail Information

Product Name: 3 Phase Natural Gas Generator
Model: GGS-400-C
Engine Brand: Cummins
Gas Type: Natural Gas
Rated Power: 400kW, 500kVA
Frequency: 50Hz
Rated Voltage: 230V, 400V
Rated Current: 720A
Engine Type: 12 Cylinder
Alternator Type: Brushless and Self-excited
Phase/Wire: 3 Phase, 4 Wire
Overall Size (L x W x H): 4510 x 1850 x 2400 mm

Technical Data

Generator Specification
Generator Set Model	GGS-400-C
Rated Power	400 kW / 500 kVA
Rated Speed/Rated Frequency	1500 rpm/50Hz
Rated Voltage	400/230V
Power Factor	0.8
Phase/Wire	3 Phase/4 Wire
Rated Current	720 A
Gas Type	Natural Gas
Overall Size	4510 x 1850 x 2400 mm
Weight	8450 kg
Engine Specification
Engine Model	Cummins KTA38
Air Intake Way	Turbo Intercooled
Cooling Way	Closed Cooling Cycle
Cylinder	12
Displacement	38 L
Bore × Stroke	159 x 159 mm
Max. standby Power @50Hz	440 kW / 550 kVA
Alternator Specification
Alternator Model	STAMFORD HCI544C
Excitation way	Brushless and Self-excited
Voltage control	AVR
Insulation Class	H
Protection	IP23
