198kW Diesel Generator, Perkins 1056A-E88TAG1, Water Cooled

Name: 198kW Diesel Generator, Perkins 1056A-E88TAG1, Water Cooled
SKU: GGS-240329-DGS-04
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Achieve dependable power supply with our 60Hz diesel generator, offering a robust prime power output of 198kW and 248kVA. Equipped with a Perkins 1056A-E88TAG1 engine, a Stamford UCDI274J alternator, and featuring water cooling and electronic governor systems, ensuring reliable performance for your operational needs.

Request a quote

Detail Information

Product Name: 198kW Diesel Generator
Model: GGS-248-P
Frequency: 60Hz
Prime Power: 198kW, 248kVA
Standby Power: 218kW, 272kVA
Rated Voltage: 127V, 220V
Displacement: 8.8 L
Bore x Stroke: 112 x 149 mm
Compression Ratio: 16.1:1
Engine: Perkins 1056A-E88TAG1, 4 Stroke, 6 Cylinder Vertical in Line
Alternator: Stamford UCDI274J, Brushless, Self-excited
Other Feature: 3 Phase, Water Cooled, Electronic Governor

Technical Data

Generator Specification
Generator Model	GGS-248-P
Frequency	60Hz
Prime Power	198kW/248kVA
Standby Power	218kW/272kVA
Rated Voltage	220V, 127V
Dimension (L x W x H) (mm)	2500 x 900 x 1750
Gross Weight (KG)	1800
Engine Specification
Engine Brand	Perkins
Engine Model	1056A-E88TAG1
Cooling System	Water Cooled
Aspiration	Turbocharged, Aftercooled
Number of Cylinders	6 Cylinder, Vertical in Line
Cycle	4 Stroke
Displacement	8.8 L
Bore x Stroke	112 x 149 mm
Compression Ratio	16.1:1
Rated Speed	1800 RPM
Governor type	Electronic
Alternator Specification
Alternator Brand	Stamford
Alternator Model	UCDI274J
Excitation system	Brushless, Self-excited
Number of phase	3 Phase
Power Factor	0.8
Protection Grade	IP23
Insulation Class	H
