1875kVA Diesel Generator, 50Hz, Perkins 4016TAG1A, 4 Stroke

Name: 1875kVA Diesel Generator, 50Hz, Perkins 4016TAG1A, 4 Stroke
SKU: GGS-240325-DGS-04
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Introducing our 1500 kW (1875 kVA) Diesel Generator, operating at 50Hz and powered by the Perkins 4016TAG1A engine. This generator features a 4-stroke, 16-cylinder Vee-form configuration and is equipped with a Stamford PI734E alternator. With water cooling and an electronic governor, trust in our generator for reliable and efficient power supply.

Request a quote

Detail Information

Product Name: 1875kVA Diesel Generator
Model: GGS-1875-P
Prime Power: 1500kW, 1875kVA
Frequency: 50Hz
Rated Voltage: 400V, 230V
Engine Model: Perkins 4016TAG1A
Engine Type: 4 Stroke, 16 Cylinder, Vee form
Alternator Model: Stamford PI734E
Alternator Type: Brushless, Self-excited
Other Feature: 3 Phase, Water Cooled, Electronic Governor

Technical Data

Generator Specification
Generator Model	GGS-1875-P
Frequency	50Hz
Prime Power	1500kW/1875kVA
Standby Power	1650kW/2062kVA
Rated Voltage	230V, 400V
Dimension (L x W x H) (mm)	7000 × 2300 × 2800
Gross Weight (KG)	7800
Engine Specification
Engine Brand	Perkins
Engine Model	4016TAG1A
Cooling System	Water Cooled
Aspiration	Turbocharged
Number of Cylinders	16 Cylinder, Vee form
Combustion System	Direct Injection
Cycle	4 Stroke
Displacement	61.123 L
Bore x Stroke	160 x 190 mm
Compression Ratio	13.6:1
Rated Speed	1500 RPM
Start Mode	Electric
Governor type	Electronic
Alternator Specification
Alternator Brand	Stamford
Alternator Model	PI734E
Excitation system	Single Bearing, Brushless, Self-excited
Number of phase	3 Phase
Power Factor	0.8
Protection Grade	IP23
Insulation Class	H
