158kW Diesel Generator, 60Hz, Perkins 1106A-70TGA3, 4 Stroke
Model Number: GGS-240328-DGS-10
Key Specifications / Features
Introducing our advanced 60Hz 4-stroke diesel generator, powered by a robust 6-cylinder Perkins 1106A-70TGA3 engine, delivering an impressive prime power output of 158kW and 180kVA. Designed for optimal performance, this generator features efficient water cooling to ensure reliable operation in various conditions.
Detail Information
Product Name: 158kW Diesel Generator
Model: GGS-180-P
Frequency: 60Hz
Prime Power: 158kW, 180kVA
Standby Power: 174kW, 218kVA
Rated Voltage: 230V, 400V
Displacement: 7.01 L
Bore x Stroke: 105 x 135 mm
Compression Ratio: 16.1:1
Engine: Perkins 1106A-70TGA3, 4 Stroke, 6 Cylinder Vertical in Line
Alternator: Stamford UCI274G, Brushless, Self-excited
Other Feature: 3 Phase, Water Cooled, Mechanical Governor
Technical Data
| Generator Specification | |
| Generator Model | GGS-180-P |
| Frequency | 60Hz |
| Prime Power | 158kW/180kVA |
| Standby Power | 174kW/218kVA |
| Rated Voltage | 230/400V |
| Dimension (L x W x H) (mm) | 2400 x 760 x 1600 |
| Gross Weight (KG) | 1800 |
| Engine Specification | |
| Engine Brand | Perkins |
| Engine Model | 1106A-70TGA3 |
| Cooling System | Water Cooled |
| Aspiration | Turbocharged, Air Charge Cooled |
| Number of Cylinders | 6 Cylinder Vertical in Line |
| Cycle | 4 Stroke |
| Displacement | 7.01 L |
| Bore x Stroke | 105 x 135 mm |
| Compression Ratio | 16.1:1 |
| Rated Speed | 1800 RPM |
| Governor type | Mechanical |
| Alternator Specification | |
| Alternator Brand | Stamford |
| Alternator Model | UCI274G |
| Excitation system | Brushless, Self-excited |
| Number of phase | 3 Phase |
| Power Factor | 0.8 |
| Protection Grade | IP23 |
| Insulation Class | H |
