Dual Port DC EV Fast Charging Station, 360kW, OCPP1.6J, IP54

Name: Dual Port DC EV Fast Charging Station, 360kW, OCPP1.6J, IP54
SKU: EVCC-DCEVC-20240809-05
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Our Dual Plug DC EV Fast Charging Station offers a maximum output of 360kW with support for OCPP 1.6J, and operates on a 380/400V AC input voltage with a frequency of 50/60Hz. It accommodates a DC voltage range of 200-1000V and features an IP54 rating for durability. This high-performance charging station provides the fastest electric car charging option, delivering up to 250 miles of range per hour, depending on the vehicle and equipment. It typically charges up to 80% in just 20 to 30 minutes. Designed to perform well in low temperatures, the station utilizes a resistive screen to ensure reliable operation in various conditions.

Request a quote

Detail Information

360kW DC EV Charging Station, OCPP 1.6J, IP54, 380/400V AC.

Rated Power: 360kW
OCPP: OCPP1.6J
DC Connectors: Dual DC Connectors(GBT + GBT),(GBT + CCS2)
Input Voltage: 380/400V AC ±10%
Input Frequency: 50/60 Hz
IP Protection: IP54
Output Current: 0-250A (GBT), 0-200A (CCS1 & CCS2)
Output Voltage: 200-1000V DC
System Efficiency: Full Load≥94%
Power Factor: ≥0.99
Harmonic Current: ≤3% (under rated operation condition)
Output Current Accuracy: ≤±0.5%
Output Voltage Accuracy: ≤±0.5%
Grounding Detection: ≤30mA
Protection: Over current protection, Residual current protection, Ground protection, Surge protection, Over/Under voltage protection, Over/Under frequency protection, Over/Under temperature protection.
Cable Length: 5 Meter
Communication Interface: 4G, RS485, CAN, ETHERNET
Noise: ≤65dB (norminal input/output power, the environment temperature is 25°C)
Operating Temperature: -40°C - +50°C
Cooling Method: Forced Air Cooling
