Battery-integrated DC EV Charger, 193kWh, 204kW, CCS2

Name: Battery-integrated DC EV Charger, 193kWh, 204kW, CCS2
SKU: EVCC-DCEVC-20240808-10
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

We are a top supplier of battery-integrated DC EV chargers, offering advanced solutions with liquid cooling technology for optimal performance. Our chargers comply with the CCS2 interface standard and deliver an impressive 204kW output power. With a capacity of 193kWh, they support a versatile output range from 20kW to 100kW, accommodating various charging needs. Designed for compatibility with 220V/380V input voltages, our chargers ensure efficient and reliable charging for electric vehicles. Combining innovation and quality, our battery-integrated chargers provide superior performance, making them the ideal choice for EV operators seeking cutting-edge, high-capacity charging solutions.

Request a quote

Detail Information

204kW Battery-integrated DC EV Charger, 193kWh, CCS2 Interface Standard

Product Item: Battery-integrated DC EV Charger
Interface Standard: CCS2
Output Power: 204kW
Input Voltage: 220V/380V
Cell Type: Lithium Iron Phosphate
IP Protection: IP54
Battery Capacity: 193kWh
Rated Power: 20kW-100kW
Rated Voltage: 380V AC
Voltage Range: 200-920V AC
Cooling Mode: Liquid Cooling
Dimension: 1 3*1.1*1.98 m
Certification: CE/UL/CQC
Weight: 2600 KG
Storage Temperature: -40°C to +70°C
Operating Temperature: -25°C to +50°C
Multiple Protection: With Over Voltage Protection, Under Voltage Protection, Overcurrent Protection, Grounding Protection, Surge Protection, Short Circuit Protection.
