Cryogenic Liquid Oxygen Bulk Tank, PED, ASME
Key Specifications / Features
Cryogenic Liquid Oxygen Bulk Tank Manufacturer: High-quality Liquid Oxygen Bulk Tank, PED, ASME, Volume 5-200 M3 Covering Various Needs.
Detail Information
Due to the rapid spread of COVID-19, medical oxygen storage is particularly important. DFC committed itself to the design and manufacturing of industrial pressure vessels, especially medical liquid oxygen storage tanks. We will do our best to produce high-quality storage tanks to contribute to the fight against the epidemic.
DFC CRYOGENIC LIQUID OXYGEN STORAGE TANK
DFC CRYOGENIC LIQUID OXYGEN STORAGE TANK
DFC CRYOGENIC LIQUID OXYGEN STORAGE TANK
| TYPE | MODEL | VOLUME (M3) |
SPECIFICATION | DESIGN CODE | |
| Inside shell | Outside Shell | ||||
| Vertical | CFL-5/0.8 | 5 | φ1400X3672X6 | φ1900X5115X8 | ASME/PED |
| Vertical | CFL-5/1.6 | φ1400X3672X8 | φ1900X5115X8 | ASME/PED | |
| Vertical | CFL-10/0.8 | 10 | φ1700X4705X6 | φ2200X6035X8 | ASME/PED |
| Vertical | CFL-10/1.6 | φ1700X4705X10 | φ2200X6035X8 | ASME/PED | |
| Vertical | CFL-15/0.8 | 15 | φ1800X6214X6 | φ2300X7730X8 | ASME/PED |
| Vertical | CFL-15/1.6 | φ1800X6214X11 | φ2300X7730X8 | ASME/PED | |
| Vertical | CFL-20/0.8 | 20 | φ2100X6146X7 | φ2600X7655X8 | ASME/PED |
| Vertical | CFL-20/1.6 | φ2100X6146X12 | φ2600X7655X8 | ASME/PED | |
| Vertical | CFL-30/0.8 | 30 | φ2100X9046X8 | φ2600X10605X8 | ASME/PED |
| Vertical | CFL-30/1.6 | φ2100X9046X14 | φ2600X10605X8 | ASME/PED | |
| Vertical | CFL-50/0.8 | 50 | φ2600X9885X9 | φ3200X11670X10 | ASME/PED |
| Vertical | CFL-50/1.6 | φ2600X9885X16 | φ3200X11670X10 | ASME/PED | |
| Vertical | CFL-100/0.8 | 100 | φ3000X14670X11 | φ3600X16550X14 | ASME/PED |
| Vertical | CFL-100/1.6 | φ3000X14670X20 | φ3600X16550X14 | ASME/PED | |
| Vertical | CFL-150/0.8 | 150 | φ3200X19308X12 | φ3800X22000X14 | ASME/PED |
| Vertical | CFL-200/0.8 | 200 | φ3400X22624X14 | φ4000X25300X14 | ASME/PED |
| TYPE | MODEL | VOLUME (M3) |
SPECIFICATION | DESIGN CODE | |
| Inside shell | Outside Shell | ||||
| Horizontal | CFL-5/0.8 | 5 | φ1400X3672X6 | φ1900X4802X8 | ASME/PED |
| Horizontal | CFL-5/1.6 | φ1400X3672X8 | φ1900X4802X8 | ASME/PED | |
| Horizontal | CFL-10/0.8 | 10 | φ1700X4705X6 | φ2200X5980X8 | ASME/PED |
| Horizontal | CFL-10/1.6 | φ1700X4705X10 | φ2200X7210X8 | ASME/PED | |
| Horizontal | CFL-15/0.8 | 15 | φ1900X5626X6 | φ2400X7210X8 | ASME/PED |
| Horizontal | CFL-15/1.6 | φ1900X5626X11 | φ2400X7210X8 | ASME/PED | |
| Horizontal | CFL-20/0.8 | 20 | φ2100X6146X7 | φ2600X7310X8 | ASME/PED |
| Horizontal | CFL-20/1.6 | φ2100X6146X12 | φ2600X7310X8 | ASME/PED | |
| Horizontal | CFL-30/0.8 | 30 | φ2100X9046X8 | φ2600X10200X8 | ASME/PED |
| Horizontal | CFL-30/1.6 | φ2100X9046X12 | φ2600X10300X8 | ASME/PED | |
| Horizontal | CFL-50/0.8 | 50 | φ2600X9885X8 | φ3200X11400X10 | ASME/PED |
| Horizontal | CFL-50/1.6 | φ2600X9885X14 | φ3200X11275X10 | ASME/PED | |
| Horizontal | CFL-100/0.8 | 100 | φ3000X14670X10 | φ3600X16350X12 | ASME/PED |
| Horizontal | CFL-100/1.6 | φ3000X14670X16 | φ3600X16900X12 | ASME/PED | |
| Horizontal | CFL-150/0.8 | 150 | φ3200X19308X10 | φ3800X20700X12 | ASME/PED |
| Horizontal | CFL-200/0.8 | 200 | φ3400X22624X11 | φ4000X24500X12 | ASME/PED |
