API 5L Grade X52 ERW 3PP Coating Pipe OD 4 Inch WT 7.9 mm

Name: API 5L Grade X52 ERW 3PP Coating Pipe OD 4 Inch WT 7.9 mm
SKU: DB-Coating Pipe-725
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

China ERW 3PP Coating Pipe Factory Derbo Offers API 5L Grade X52 ERW 3PP Coating Pipe, OD 4 Inch, WT 7.9 mm, Internal Coating Novolac Epoxy, Coating.

Request a quote

Detail Information

Type: ERW 3PP Coating Pipe.
Material and Grade: API 5L Grade X52.
Size: OD 4 Inch, WT 7.9 mm.
Manufacture Method: ERW.
Surface Treatment: Oiled, Coating, Painting, Vanished, etc.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: In Bundles by Steel Strips or as Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.

API 5L PSL1 Chemical Components and Mechanical Performance
Grade		Chemical Components				Mechanical Performance
		C(Max)	Mn(Max)	P(Max)	S(Max)	Tensile Strength(Min）		Yield Strength(Min)
		C(Max)	Mn(Max)	P(Max)	S(Max)	Psi	Mpa	Psi	Mpa
A25	CL Ⅰ	0.21	0.60	0.030	0.030	45.000	310	25.000	172
A25	CL Ⅱ	0.21	0.60	0.030	0.030	45.000	310	25.000	172
A		0.22	0.90	0.030	0.030	48.000	331	30.000	207
B		0.28	1.20	0.030	0.030	60.000	414	35.000	241
X42		0.28	1.30	0.030	0.030	60.000	414	42.000	290
X46		0.28	1.40	0.030	0.030	63.000	434	46.000	317
X52		0.28	1.40	0.030	0.030	66.000	455	52.000	359
X56		0.28	1.40	0.030	0.030	71.000	490	56.000	386
X60		0.28	1.40	0.030	0.030	75.000	517	60.000	414
X65		0.28	1.40	0.030	0.030	77.000	531	65.000	448
X70		0.28	1.40	0.030	0.030	82.000	565	70.000	483
