API 5L Gr.B Seamless Pipe, 20 Inch, 12 Meters, BE Ends
Model Number: DB-CS-SMLS-1
Key Specifications / Features
China API 5L Seamless Pipe Manufacturer Derbo offers API 5L Gr.B Seamless Pipe, 20 Inch, SCH40, 12 Meters, API 5L PSL1, ASME B36.10, BE Ends, Black Coating.
Contact Supplier
Detail Information
Type: Seamless Pipe.
Material: API 5L Gr.B.
Wall Tickness: SCH.40.
Length: 12M.
Standard: API 5L PSL1, ASME B36.10.
Ends: Beveled Ends.
Surface Treatment: Black Coating.
Material: API 5L Gr.B.
Wall Tickness: SCH.40.
Length: 12M.
Standard: API 5L PSL1, ASME B36.10.
Ends: Beveled Ends.
Surface Treatment: Black Coating.
| Tolerance for wall thickness: | |
| Wall thickness t mm(in) |
Tolerances mm(in) |
| SMLS pipe | |
| ≤4.0（0.157） | +0.6(0.024) |
| +0.5(0.020) | |
| ＞4.0（0.157） to ＜25.0（0.984） | +0.150 t |
| -0.125 t | |
| ≥25.0（0.984） | +3.7(0.146) or 0.1 t,whichever is the greater |
| -3.0(0.120) or -0.1 t,whichever is the greater | |
| Welded pipe | |
| ≤5.0(0.197) | ±0.5(0.020) |
| ＞5.0(0.197) to＜15.0(0.591) | ±0.1 t |
| ≥15.0(0.591) | ±1.5(0.060) |
| Chemical Composition and Mechanical Property For PSL .1 | |||||||||
| Steel Grade | Chemical components | Mechanical performance | |||||||
| C(Max) | Mn(Max) | P | S(Max) | Tensile strenght(Min） | Yield Strenght (Min) |
||||
| Min. | Max. | psi | Mpa | psi | Mpa | ||||
| Seamless Pipe | |||||||||
| B | 0.28 | 1.20 | / | 0.030 | 0.030 | 60200 | 415 | 35500 | 245 |
