A350 LF2 WN Flange ASME B16.5 1 Inch SCH 160 2500LB Forged RTJ

Name: A350 LF2 WN Flange ASME B16.5 1 Inch SCH 160 2500LB Forged RTJ
SKU: DB-Flange-747
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

China A350 LF2 WN Flange Manufacturer Derbo Provides A350 LF2 WN Flange, ASME B16.5, 1 Inch, SCH 160, 2500LB, Forged, RTJ, Oiled, Pipe Connection.

Request a quote

Detail Information

Type: WN Flange.
Material and Grade: A350 LF2.
Standard: ASME B16.5.
Size: 1 Inch, SCH 160, 2500LB.
Seal Face: RTJ.
Manufacture Method: Forged.
Surface Treatment: Sand Blast, Oiled, Painting, etc.
Independence Inspection: Chemical Test, Mechanical Test.
Application: For Pipe Connection.
Third Party Inspection: SGS, BV, INTERNET, etc.
Packing: Pallet with Waterproof Packing/Sea Worthy Wooden Case or as Your Requirement.
Payment Terms: TT/LC, West Union, Paypal, O/A.
Delivery Time: 7-25 Days after Receiving the Deposit.

Chemical Composition and Mechanical Property for ASTM A350
Grade	Chemcial Composition											Mechanical Performance
	C(Max)	Mn	P(Max)	S(Max)	Si	Ni(Max)	Cr(Max)	Mo(Max)	Cu(Max)	Co(Max)	V(Max)	Yield Strength (Min）	Tensile Strength (Min)	Elongation (Min)
														(Min)
												Mpa	Mpa	%
LF2 Class1	0.3	0.60-1.35	0.035	0.04	0.15-0.30	0.4	0.3	0.12	0.4	0.02	0.08	250	485-655	22
LF2 Class 2	0.3	0.60-1.35	0.035	0.04	0.15-0.30	0.4	0.3	0.12	0.4	0.02	0.08	250	485-655	22
