Electric Single Seated Control Valve, CF8M, 1/2 - 1-1/2 Inch

Name: Electric Single Seated Control Valve, CF8M, 1/2 - 1-1/2 Inch
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a specialized factory in stainless steel single-seated control valves, we offer high-quality valves equipped with electric actuators for precise control. Our valves are made from ASTM A351 CF8M stainless steel, ensuring durability and corrosion resistance. Available in sizes ranging from 1/2 inch to 1-1/2 inches and pressure classes of 150-300 LB, these valves feature a globe body design with SS 316 plugs and seats, providing reliable performance in various industrial applications.

Request a quote

Detail Information

• Nominal diameters
1/2 - 1-1/2 Inch, DN15 – DN150

• Nominal pressure values
Class 150 - 300 LB, PN16 – PN40

• Design
single seated globe valve

• Operating temperature range
-20°C to +205°C

• Flow characteristics
linear
equipercent

• Flow coefficient Kvs
0.09 – 256 [m3.h-1]

• Leakage class (IEC 60534-4)
Class IV
Class V
Class VI

• Body material
ductile iron GGG40
carbon steel GP240 GH(1.0619), A216 WCB
stainless steel CF8M

• Plug and seat material
stainless steel AISI 316L, 17-4PH

• Connection
flange

• Type of actuator
pneumatic diaphragm (with handwheel)
electric
