Pneumatic Butterfly Control Valve, ASTM A351 CF8, 6 IN, CL150
Model Number: CNCV-240615-BFCV-02
Key Specifications / Features
Our Pneumatic Butterfly Control Valve is crafted from Stainless Steel ASTM A351 CF8. It features a 6-inch size with a Class 150 LB rating, DN150 nominal diameter, and PN16 pressure rating. Equipped with a pneumatic rack and pinion actuator, this valve provides reliable and precise flow control in industrial applications. Ideal for use in sectors such as chemical processing, water treatment, and HVAC systems, it ensures durability and efficient operation
Detail Information
Product Name: Pneumatic Butterfly Control Valve
Material: Stainless Steel ASTM A351 CF8
Size: 6 Inch, DN150
Pressure: Class 150 LB, PN16
Actuation: Pneumatic Rack and Pinion Actuator
Product Range
Body Material: Ductile Iron, Cast Steel, Stainless Steel, Bronze
Seal Material: PTFE, RPTFE
Size Range: 2-40 Inch, DN50-DN1000
Pressure Rating: Class 150 LB, PN10, PN16
End Connection: Wafer, Lug, Semi-lug
Ambient temperature: -30°C to 70°C
Working Temperature: -20°C to 90°C
Actuator Options: Single or Double Acting Pneumatic Actuators
Supply Pressure: 400 to 700 KPa
