ASTM A105 Labyrinth Control Valve, 4 Inch, 1500 LB, Flanged
Model Number: CNCV-240520-UCV-07
Key Specifications / Features
Manufactured in China, this Labyrinth Control Valve is crafted from durable carbon steel ASTM A105, ensuring reliability and longevity. Sized at 4 inches (DN100) with a Class 1500 LB rating (PN250), it's suitable for high-pressure applications. The valve features ANSI Class IV seat leakage standards for tight shutoff and minimal leakage. Equipped with flanged ends for easy installation and maintenance. Ideal for industries requiring dependable flow regulation in demanding environments.
Detail Information
Product Name: ASTM A105 Labyrinth Control Valve
Key Features: Labyrinth Cage
Material: ASTM A105
Size: 4 Inch, DN100
Pressure: Class 1500 LB, PN250
End Connection: Flanged
Seat Leakage: ANSI Class IV (0.01%)
Product Range
Size Range: 1-1/2 - 12 Inch, DN40-DN300
Pressure Rating: Class 900-2500 LB, PN160-PN420
Body Material: ASTM A216 WCB, ASTM A105, ASTM A217 WC6, ASTM A352 LCB, ASTM A351 CF8, CF8M, CF3, CF3M
Temperature Range: -196℃ to +540℃
Bonnet Type：Standard, Fin-Extension
