Soft Seal Ball Valve, Butt Welded, ASTM A216, DN15-200
Key Specifications / Features
Detail Information
Soft seal ball valve is used to cut off or connect medium in pipelines. It is applicable for water, gas, oil and corrosive medium.
Working temperature: -196~350℃
Actuator: manual, pneumatic, electric
Nominal diameter: DN15-200mm, 1/2″-10″
Standards
|
Standard |
National Standard |
American Standard |
|
|
Design |
GB/T12237 |
API 6D |
ANSI B16.34 |
|
Length (flanged) |
GB/T12221 |
API 6D |
ANSI B16.10 |
|
Length(butt welded) |
GB/T15188.1 |
API 6D |
ANSI B16.10 |
|
Flanged |
GB/T9113 |
ANSI B16.5, B16.47 |
|
|
Butt Welded |
GB/T12224 |
ASNI B16.25 |
|
|
Testing & Inspection |
GB/T9092 |
API 6D |
AP1598 |
Materials
|
NO. |
Part Name |
Materials |
|
|
GB |
ASTM |
||
|
1 |
Body |
WCB |
A216-WCB |
|
2 |
Seal ring |
PTFE |
PTFE |
|
3 |
ball |
1Cr18Ni9Ti |
SS304 |
|
4 |
Nut |
35 |
A194-2H |
|
5 |
Bolt |
35CrMoA |
A193-B7 |
|
6 |
Substance |
WCB |
A216-WCB |
|
7 |
Gasket |
Flexible graphite + stainless steel |
B12.10-304/F.G |
|
8 |
Packing |
PTFE |
PTFE |
|
9 |
Packing gland |
WCB |
A216-WCB |
|
0 |
Spacer |
25 |
A105 |
|
11 |
Bead Flange |
65Mn |
AISI 1066 |
|
12 |
Handle |
K33 |
A47-667 Gr.32510 |
|
13 |
Stem |
1Cr33 |
A276-410 |
|
14 |
Screw |
35 |
A193-B7 |
|
15 |
Thrust gasket |
PTFE |
PTFE |
Dimensions
PN1.6MPa
|
Nominal Diameter DN |
15 |
20 |
25 |
32 |
40 |
50 |
65 |
80 |
100 |
125 |
150 |
200 |
|
L |
130 |
140 |
150 |
165 |
180 |
200 |
220 |
250 |
280 |
320 |
360 |
400 |
|
H |
59 |
63 |
75 |
85 |
95 |
107 |
140 |
152 |
178 |
252 |
272 |
342 |
|
W |
130 |
130 |
160 |
180 |
230 |
230 |
400 |
400 |
650 |
1050 |
1050 |
1410 |
|
Wt(㎏) |
2.5 |
3 |
5 |
6 |
7 |
10 |
15 |
19 |
33 |
58 |
93 |
160 |
PN2.5MPa
|
Nominal Diameter DN |
15 |
20 |
25 |
32 |
40 |
50 |
65 |
80 |
100 |
125 |
150 |
200 |
|
L |
130 |
140 |
150 |
165 |
180 |
200 |
220 |
250 |
280 |
320 |
360 |
400 |
|
H |
59 |
63 |
75 |
85 |
95 |
107 |
140 |
152 |
178 |
252 |
272 |
342 |
|
W |
130 |
130 |
160 |
180 |
230 |
230 |
400 |
400 |
650 |
1050 |
1050 |
1410 |
|
Wt(㎏) |
2.5 |
3 |
5 |
6 |
7 |
10 |
15 |
19 |
33 |
58 |
93 |
160 |
PN4.0MPa
|
Nominal Diameter DN |
15 |
20 |
25 |
32 |
40 |
50 |
65 |
80 |
100 |
125 |
150 |
200 |
|
L |
130 |
140 |
150 |
165 |
180 |
200 |
220 |
250 |
280 |
320 |
360 |
400 |
|
H |
59 |
63 |
75 |
85 |
95 |
107 |
140 |
152 |
178 |
252 |
272 |
342 |
|
W |
130 |
130 |
160 |
180 |
230 |
230 |
400 |
400 |
650 |
1050 |
1050 |
1410 |
|
Wt(㎏) |
2.5 |
3 |
5 |
6 |
7 |
10 |
15 |
19 |
33 |
58 |
93 |
160 |
