250kW Diesel Generator Set, Cummins NTA855-G1B, Trailer Type
Key Specifications / Features
Detail Information
Product Name: 250kW Diesel Generator Set, Trailer Mounted, Customized
Fuel Type: Diesel
Engine: Cummins NTA855-G1B
Frequency: 50 Hz
Rated Power: 250kW, 313kVA
Standby Power: 275kW, 344kVA
Output Voltage: 230/400 V
Rated Current: 450 A
Rated Speed: 1500 rpm
Noise Level (7m): 78 dB
Power Factor: COSΦ = 0.8 (lagging)
Phase/Wires: 3-phase, 4-wire
Start Mode: Electric
Fuel Consumption: 54.3 L/h (average)
Protection: Low oil pressure, High water temp, Over-speed, Over-current
Engine Specifications
|
Engine Brand |
Cummins |
|
Engine Model |
NTA855-G1B |
|
Engine Cylinders |
6 |
|
Fuel Type |
0# light diesel |
|
Inter-Cooling |
Water inter-cooling |
|
Compression Ratio |
13.0:1 |
|
Engine Power (Prime/Standby) |
283kW/311kW |
|
Aspiration |
Turbocharged / Water-Air Inter-cooled |
|
Governor/Class |
Electric |
|
Bore and Stroke |
140 × 152 mm |
|
Start Mode |
DC 24V electric start |
|
Cylinders Layout |
In-line |
|
Displacement |
14 L |
Alternator Specifications
|
Alternator Brand |
Stamford |
|
Alternator Model |
HCI444ES |
|
Protection |
IP23 |
|
Frequency Fluctuation |
≤ ±0.5 % |
|
Voltage Distortion |
< 4% |
|
Prime Power |
325 kVA (260 kW) |
|
Original |
China |
|
Rated Voltage |
400/230 V |
|
Frequency Regulation |
≤ ±0.5 % (stable) |
|
Voltage Control |
AVR |
Control Panel Technical Parameters
|
Control Panel Brand |
Deep Sea |
|
Model |
6020 |
|
Start/Stop Function |
Manual/Automatic |
|
Pre-heat/Idle Output |
Definable |
|
High Coolant Temperature Protection |
Yes |
|
Low Oil Pressure Protection |
Yes |
|
Overload Protection |
Yes |
|
Generator Over/Under Frequency Protection |
Yes |
|
Generator Over/Under/Unbalance Voltage Protection |
Yes |
|
Over Speed Protection |
Yes |
|
AMF (Automatic Mains Failure) |
Yes |
Features of Trailer Generator Sets
- Soundproof Design: Incorporates all the benefits of soundproof generator sets, ensuring minimal noise pollution.
- Outdoor Compatibility: Ideally suited for outdoor operations, providing reliable power in various environments.
- Balanced Towing Setup: The towing device is strategically positioned on the wheel chassis to maintain balance during transportation.
- Safety Compliance: Equipped with warning lamps that adhere to transport safety standards, enhancing visibility and safety.
- Optional Cable Rack: Available with a cable rack for convenient storage and management of cables.
- Customizable Axle and Brake Options: Offers single-axle or double-axle configurations, as well as mechanical or automatic brake systems, to meet diverse requirements.
- Secure Fuel Filling System: Features a convenient fuel filling system with a lockable fuel cap for added security.
- Versatile Trailer Types: Available in both 2-wheel and 4-wheel trailer configurations to suit different needs.
