PPH Pneumatic Ball Control Valve, UPVC, 1/2-4 Inch, 150 LB

Discover our PPH Pneumatic Ball Control Valve, crafted for superior performance and versatility. Operated pneumatically, it ensures precise control over fluid flow. Available in sizes ranging from 1/2 to 4 inches (DN15-DN100) and compatible with Class 150 LB and PN16 pressure ratings, it adapts seamlessly to various systems. Constructed from robust materials including UPVC, CPVC, PVDF, PP, and ABS, it offers exceptional durability and chemical resistance. With socket, threaded, and flanged connection options, installation is effortless. Elevate your operations with our valve, delivering reliable performance, durability, and adaptability across a wide range of applications.

SPECIFICATIONS
Product Name: PPH Pneumatic Ball Control Valve
Body Material: UPVC, CPVC, PPH, PVDF, PP, ABS
Ball: UPVC, CPVC, PPH
Seat: PTFE
End: BSP, BSPT, NPT, DIN, ISO, Double Connection
Size Range: 1/2 Inch - 4 Inch, DN15-DN100
Pressure: PN16, Class 150 LB
End Connection: Socket, Threaded, Flanged
Medium: Gas, Water and Oil, etc
Option: Olenoid Valve, Limit Switch Box , Filter, E/P Positioner, Hand Wheel.
Pneumatic Actuator: Double Acting, Single Acting Normally Closed, Acting, Single Normally Open.
