Pneumatic Ball Valve, 1/2-8 Inch, PN16-PN64, ASTM A351 CF8

Name: Pneumatic Ball Valve, 1/2-8 Inch, PN16-PN64, ASTM A351 CF8
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Discover our ASTM A351 CF8 Pneumatic Ball Valve, designed for superior performance and reliability. This pneumatic-operated valve features double-acting functionality and is constructed from durable stainless steel. Available in sizes ranging from 1/2 to 8 inches (DN15-DN200), it suits a variety of applications. With pressure ratings from PN16 to PN64 and Class 150 to 400 LB, it ensures dependable operation under diverse conditions. The flanged design facilitates easy installation and maintenance. Ideal for industrial environments, our valve offers robust construction, corrosion resistance, and efficient flow control. Choose our valve for its high quality and versatile performance in demanding applications.

Request a quote

Detail Information

SPECIFICATIONS
Product Name: Pneumatic Operated Ball Control Valves
Size Range: 1/2 Inch - 8 Inch, DN15-DN200
Pressure Rating: PN16-PN64, Class 150 LB - 400 LB
Material: ASTM A351 CF8, Stainless Steel
Valve Ball: Stainless Steel
Sealing Material: PTFE
Acting Mode: Double Acting
End Connection: Flange
Media: Water, Oil, Gas, Air
Temperature of Media: -10°C to 180°C
