Pneumatic Angle Control Valve, 1/2-2 Inch, Class 150-2500 LB
Model Number: CNCV-240508-ACV-01
Key Specifications / Features
Discover our Pneumatic Angle Control Valve Plant, featuring an unbalanced plug design with top guidance. Available in sizes ranging from 1/2 to 2 inches, with pressure ratings from Class 150 to 2500 LB. Crafted from robust materials such as ASTM A216 WCB, A217 WC6, A352 LCB, and more, ensuring reliability in diverse applications.
Detail Information
Product Name: Pneumatic Angle Control Valve
Key Features: Unbalanced Plug, Top Guided, Single-Seated
Size Range: 1/2 Inch - 2 Inch, DN15-DN50
Pressure Rating: Class 150 LB - 2500 LB, PN20-PN420
Body Material: ASTM A216 WCB, ASTM A217 WC6, ASTM A352 LCB, ASTM A351 CF8, CF8M, CF3, CF3M
Seat Leakage: ANSI B16.104 Class IV
Rangeability: 30:1 to 10:1
Actuator: Multi-spring Diaphragm Actuator
Connection: Flange (FF, RF, RJ, RTJ), Socket Weld, Butt Weld
Temperature Range: -196℃ to +550℃
Flow Characteristic: Linear, Equal Percentage (EQ%)
Supplier Information
Control Valve (Zhejiang) Co., Ltd.
Verified Supplier
Yongjia, Wenzhou, Zhejiang, P. R. China
Est. 1988
Certifications:
ISO 9001
