Non-Lubricating Globe Control Valve, 1-4 IN, 150-600 LB, WCB

Name: Non-Lubricating Globe Control Valve, 1-4 IN, 150-600 LB, WCB
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

This globe control valve features integral end connections, post guiding, and a quick-change trim design. Ideal for chemical and hydrocarbon processing, it excels in handling viscous, non-lubricating, and other challenging fluids. The valve accommodates various end connection styles, including flanged Class 150, 300, and 600 raised face, ring-type joint, or flat face, adhering to ASME B16.5 standards. Additionally, screwed connections meet Class 600 specifications as per the latest ASME B16.34 edition, ensuring versatile application and robust performance.

Request a quote

Detail Information

SPECIFICATIONS

Product Name: Cage-guided Globe Control Valves
Key Features: Cage-guided, Non-lubricating, Globe Style
Size Range: 1 Inch - 4 Inch, DN25-DN100
Pressure: Class 150 LB - 600 LB
Body Materials: ASTM A352 LCC, ASTM A216 WCB, WCC, ASTM A217 WC9, C5, Monel, ASTM A351 CF8M SST.
Trim Materials:
Standard Material: Stainless Steel, SS 316.
Optional Material: Alloy 6, Cobalt, Tungsten Carbide.
Seats: Metal and TFE
Shutoff: Class IV & V
Flow Characteristics:
Linear
Quick Opening
Equal Percentage
Noise Abatement
Anti-Cavitation
Flow Direction: Flow Up Through the Seat Ring.

Features & Benefits

1. Offers characterized flow options such as equal percentage, linear, and quick opening.
2. Available in various body and trim materials to suit diverse applications.
3. Features quick-change trim for easy maintenance.
4. Optional NACE MRO 175 / ISO 15156-2009 for sour service capability.
5. Ensures tight shutoff for reliable operation.
