Motorized Butterfly Control Valves, 8-80 IN, Flanged

Name: Motorized Butterfly Control Valves, 8-80 IN, Flanged
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Introducing our Motorized Butterfly Control Valves, designed for precision flow control and remote operation. These valves integrate seamlessly into automation systems, offering quick response times and enhanced energy efficiency. Available in various materials and sizes, they are ideal for HVAC, water treatment, chemical processing, and more. Durable and low-maintenance, our valves ensure long-term reliability and cost-effectiveness. With built-in safety features and the ability to handle demanding environments, they provide a versatile and efficient solution for your flow control needs. Optimize your processes with our high-performance motorized butterfly control valves.

Request a quote

Detail Information

SPECIFICATIONS
Product Name: Motorized Butterfly Control Valves
Size Range: 2 Inch - 40 Inch, DN50-DN1000
Pressure Rating: Class 150 LB - 300 LB
Electric Actuator: ON/OFF type, Adjustable type
Body Material: Cast Iron, Ductile Iron, Aluminum Stainless Steel, ASTM A351 CF8, CF8M, CF3, CF3M
Disc: Stainless Steel, ASTM A351 CF3M, CF3, CF8M, Nylon Coated Ductile Iron, Aluminum Bronze, Double Stainless
Seat: NBR (Nitrile Butadiene Rubber), EPDM (Ethylene Propylene Diene Monomer), Viton (Fluoroelastomer)
Control signal: 4-20 mADC, 0-5 VDC, 0-10 VDC
Power: 12 VDC, 24 VAC, 24 VDC, 220 VAC, 120 VAC, 380 VAC 50/60 Hz ±10%
End Connection: Wafer, Lug
Medium: Gas, Water and Oil, etc
