Electrically-Actuated Control Valve, DN100, PN160, ASTM A105

Name: Electrically-Actuated Control Valve, DN100, PN160, ASTM A105
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Adhering to ANSI/ISA 75.01.01 and ASME B16.34 standards and made from ASTM A105 material, our electric globe control valves are essential components in industrial automation. They are widely used in the oil, chemical, power generation, and pharmaceutical sectors. Our experts provide detailed guidance on model parameters and operational conditions to help you select and utilize the optimal electric control valves for your specific needs, ensuring high performance and reliability in demanding applications.

Request a quote

Detail Information

SPECIFICATIONS
Product Name: Electrically-Actuated Control Valve
Pressure Rating: Class 150 LB - 2500 LB, PN16-PN260
Design Standard: ANSI/ISA 75.01.01 & ASME B16.34
Face to Face Standard: ASME B16.10
Flange Standard: ASME B16.5
Materials: ASTM A105, ASTM A216 WCB, WC6, ASTM A351 CF8, CF8M, CF3M, CF3, ASTM A352 LCB
Sizes: 1 Inch - 24 Inch, DN25-DN600
Temperature Range: -196 to +550°C
Electric Actuator Basics:
Power Supply: Options DC24V, AC220V, AC380V.
Input Control Signal: Typically 4-20MA or DC1-5V.
Feedback Control Signal: Usually DC4-20MA (load resistance under 500 ohms).
Flow Characteristics: linear, equal percentage, and parabolic options
