Electric Globe Control Valve, ASTM A351 CF8M, 2 Inch, 150 LB
Key Specifications / Features
Introducing the Electric Globe Control Valve, crafted to ANSI/ISA 75.01.01 & ASME B16.34 standards, featuring ASTM A351 CF8M body materials. Available in sizes ranging from 1 inch to 24 inches (DN25 to DN600), with ANSI Class ratings from Class 150 LB to 2500 LB and pressure ratings from PN20 to PN420. Operating within a temperature range of -196 to +550°C, these valves are vital in industrial automation across sectors like oil, chemicals, power generation, and pharmaceuticals. Our expert guidance ensures optimal selection and utilization, tailored to your specific requirements.
Detail Information
SPECIFICATIONS
Product Name: Electric Globe Control Valves
Product Name: Electric Actuated Control Valve
Design Standard: ANSI/ISA 75.01.01 & ASME B16.34
Body Materials: ASTM A351 CF8M, CF8, CF3M, CF3, ASTM A216 WCB, A216 WCC, A216WC6, ASTM A352 LCB
Face to Face Standard: ASME B16.10
Flange Standard: ASME B16.5
Size Ranges: 1 - 24 Inch, DN 25-DN 600
ANSI Class: Class 150 LB-2500 LB, PN20-PN420
Temperature Range: -196 to +550°C
Flow Characteristics: Equal Percentage, Linear
Electric Actuator Basics:
Power Supply: Options DC 24V, AC 220V, AC 380V.
Input Control Signal: Typically 4-20 MA or DC 1-5V.
Feedback Control Signal: Usually DC 4-20 MA (load resistance under 500 ohms).
Product Name: Electric Globe Control Valves
Product Name: Electric Actuated Control Valve
Design Standard: ANSI/ISA 75.01.01 & ASME B16.34
Body Materials: ASTM A351 CF8M, CF8, CF3M, CF3, ASTM A216 WCB, A216 WCC, A216WC6, ASTM A352 LCB
Face to Face Standard: ASME B16.10
Flange Standard: ASME B16.5
Size Ranges: 1 - 24 Inch, DN 25-DN 600
ANSI Class: Class 150 LB-2500 LB, PN20-PN420
Temperature Range: -196 to +550°C
Flow Characteristics: Equal Percentage, Linear
Electric Actuator Basics:
Power Supply: Options DC 24V, AC 220V, AC 380V.
Input Control Signal: Typically 4-20 MA or DC 1-5V.
Feedback Control Signal: Usually DC 4-20 MA (load resistance under 500 ohms).
