Electric Damper Butterfly Control Valve, 2-120 IN, Cast Iron

Name: Electric Damper Butterfly Control Valve, 2-120 IN, Cast Iron
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Introducing our Electric Damper Butterfly Control Valve: meticulously crafted to deliver precise On/Off functionality in environments with elevated temperatures. Constructed from robust Cast Iron or resilient Ductile Iron, these valves are engineered to meet stringent PN60 and Class 900 LB standards, ensuring steadfast performance even in the harshest conditions. With sizes ranging from 2 to 120 inches (DN25 to DN3000), they offer unparalleled versatility in fluid control solutions. Experience the multitude of benefits they bring, including enhanced energy efficiency, lightning-fast response times, remote operability, and seamless integration with automation systems. Perfectly suited for HVAC systems, water treatment plants, chemical processing, and beyond, our electric damper butterfly valves epitomize reliability, efficiency, and cost-effectiveness.

Request a quote

Detail Information

SPECIFICATIONS
Product Name: Electric Damper Butterfly Control Valve
Body Material: Cast Iron, Ductile Iron, Stainless Steel, ASTM A351 CF8, CF8M, CF3M, CF3
Disc: Stainless Steel, ASTM A351 CF3M, CF3, CF8M, SAF 2507, 1.4529, 310S
Size Range: 2 Inch - 120 Inch, DN25-DN3000
Pressure: PN60, Class 900 LB
Medium: Gas, Water and Oil, etc
Electric Actuator: ON/OFF type, Adjustable type
Control signal: 4-20 mADC, 0-5 VDC, 0-10 VDC
Power: 12 VDC, 24 VAC, 24 VDC, 220 VAC, 120 VAC, 380 VAC 50/60 Hz ±10%
