Eccentric Rotary Plug Control Valve, 1-12 Inch, 150-600 LB
Key Specifications / Features
We supply high-quality Eccentric Rotary Plug Control Valves crafted from ASTM A216 WCC and ASTM A351 CF8M materials. Available in sizes ranging from 1 to 12 inches (DN25-DN300) and suitable for Class 150-600 LB (PN10-PN100) applications, these valves are complemented by reliable Pneumatic Actuators for efficient operation.
Request a quote
Detail Information
Product Name: Eccentric Rotary Plug Control Valve
Key Features: Quarter Turn Eccentric Rotary Plug
Size Range: 1-12 Inch, DN25-DN300
Pressure Range: Class 150-600 LB, PN10-PN100
Body Material: Carbon Steel ASTM A216 WCC, Stainless Steel ASTM A351 CF8M
End Connection: Flanged
Actuator: Pneumatic Actuator
Temperature Range: -200 °C to +450 °C
Flow Characteristics: Linear
Rangeability: 50:1
Leakage: ANSI/FCI 70-2 Class IV (Metal Seat) and Class VI (Soft Seat)
