Diaphragm Actuator Control Valve, 1/2-12 Inch, ASTM A216 WCB
Key Specifications / Features
The pilot-operated pressure regulator (before-valve control) consists of a control valve, actuator, and a pilot for pressure setting. It is designed to manage differential pressure in pipes carrying non-corrosive liquids, gases, and vapors. When the upstream pressure increases, the control valve opens. This self-operated, straight-through regulator features a piston actuator and is available in sizes DN15-DN300 (1/2-12 Inch), with pressure ratings of PN16, PN40, and Class 150 LB, 300 LB.
Request a quote
Detail Information
SPECIFICATIONS
Product Name: Diaphragm Actuator Control Valve
Key Features: Self-operated, Straight-through, Diaphragm Actuator, Piston Actuator
Body Material: ASTM A216 WCB, ASTM A315 CF8, CF8M, CF3M
Size Range: DN15-DN300, 1/2 Inch - 12 Inch
Pressure Rating: Class 150 LB - 300 LB, PN16-PN40
Body Type: Straight-through
Flow characteristic: Quick Open
Bonnet Type: Standard, Heat Dissipation
Set Value Error: ±4%
Leakage class: ASME B16.104 Ⅴ(soft seal), ASME B16.104 Ⅳ(hard seal)
Working Temperature: -30°C to 350°C
Product Name: Diaphragm Actuator Control Valve
Key Features: Self-operated, Straight-through, Diaphragm Actuator, Piston Actuator
Body Material: ASTM A216 WCB, ASTM A315 CF8, CF8M, CF3M
Size Range: DN15-DN300, 1/2 Inch - 12 Inch
Pressure Rating: Class 150 LB - 300 LB, PN16-PN40
Body Type: Straight-through
Flow characteristic: Quick Open
Bonnet Type: Standard, Heat Dissipation
Set Value Error: ±4%
Leakage class: ASME B16.104 Ⅴ(soft seal), ASME B16.104 Ⅳ(hard seal)
Working Temperature: -30°C to 350°C
