Desuperheater Control Valves, Class 150-2500 LB, 1-24 Inch
Key Specifications / Features
Presenting our Desuperheater Control Valves, expertly designed for precise steam temperature regulation. Available in pneumatic construction, Non-Integral type, with sizes ranging from 1 to 24 inches (DN25-DN250), and pressure ratings from Class 150 LB to 2500 LB (PN25-PN420). Featuring both Flanged and Butt Weld Ends for flexible installation options. Desuperheater valves play a crucial role in reducing steam temperature by spraying water into the steam flow. We offer two types: Non-Integral, with separate desuperheater nozzle and water valve units, and Integral, integrating the desuperheater with the actuator. Nozzle options include Venturi type and Variable orifice for precise control over flow and pressure variations.
Request a quote
Detail Information
SPECIFICATIONS
Product Name: Desuperheater Control Valve
Size Range: 1 Inch - 24 Inch, DN25-DN250
Pressure Rating: Class 150 LB - 2500 LB, PN25-PN420
Body Type: Variable Area Nozzles Spray Pipeline Desuperheater
Actuator Options: Pneumatic Spring Return Diaphragm
End Connections:
Steam Pipe: Flanged, Butt Weld
Water Pipe: Flanged
Leakage Class: Class IV (ANSI FCI/70-2)
Inherent Characteristics: Linear & Equal %
Product Name: Desuperheater Control Valve
Size Range: 1 Inch - 24 Inch, DN25-DN250
Pressure Rating: Class 150 LB - 2500 LB, PN25-PN420
Body Type: Variable Area Nozzles Spray Pipeline Desuperheater
Actuator Options: Pneumatic Spring Return Diaphragm
End Connections:
Steam Pipe: Flanged, Butt Weld
Water Pipe: Flanged
Leakage Class: Class IV (ANSI FCI/70-2)
Inherent Characteristics: Linear & Equal %
