Y Pattern Globe Valve, API 602, 1500 LB, 1/2 IN, ASTM A105N
Key Specifications / Features
As an API 602 globe valve exporter from China, we offer high-quality valves crafted to ASME B16.34 standards and made from ASTM A105N material. Our valves, rated at Class 1500 LB and sized at 1/2 inch, feature a pressure seal bonnet for exceptional leak protection and durability. Equipped with a butt weld end for secure, permanent installation and a handwheel for precise operation, these valves are designed for demanding high-pressure applications. Rely on our expertise for reliable, top-performance globe valves that meet your industrial needs with precision and strength.
Request a quote
Detail Information
API 602 Y Globe Valve, Pressure Seal Bonnet, 1/2 Inch, 1500 LB, A105N Body, for Power Plant.
Valve Description:
1852040 Globe Valve
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, Pressure Seal Bonnet, Welded Bonnet, Bonnetless
Nominal Size: 1/2 Inch
Nominal Class: 1500 LB
Bore Type: Reduced
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Operation: Handwheel
Body Material: ASTM A105N, ASTM A182 F11, ASTM A182 F22, ASTM A182 F316, ASTM A182 F91
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Face to Face: MFG'S
Test and Inspection: API 598
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
Valve Description:
1852040 Globe Valve
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, Pressure Seal Bonnet, Welded Bonnet, Bonnetless
Nominal Size: 1/2 Inch
Nominal Class: 1500 LB
Bore Type: Reduced
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Operation: Handwheel
Body Material: ASTM A105N, ASTM A182 F11, ASTM A182 F22, ASTM A182 F316, ASTM A182 F91
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Face to Face: MFG'S
Test and Inspection: API 598
Key Features:
Rising Stem with Handwheel
Available with Swivel, Plug, or Needle Disc
Y Pattern
OS&Y
Live Load Packing
Backseat
Compact and Robust Body Suitable for High-Temperature and High-Pressure Service
| Product Line | |
| Body Material: | Carbon Steel, Stainless Steel, Alloy Steel |
| Normal Diameter: | 1/2 Inch - 2 Inch (DN15-DN50) |
| Pressure Range: | Class 800 LB - 4500 LB |
| Working Temperature: | -29°C - +525°C |
| Operation: | Manual or Actuated |
| End Connection: | BW/SW/NPT |
Send your message to this supplier
FAQs
OS&Y stands for Outside Screw and Yoke. This design places the threaded stem outside the valve body, with the yoke supporting the stem. It allows users to visually verify whether the valve is open or closed by observing the stem’s position.
OS&Y gate valves are commonly used in fire protection systems, including sprinklers, hydrants, and standpipes, due to their reliability and clear open/close indication.
