UNS N08020 Globe Valve, Nickel Alloy 20, 1 Inch, 800 LB

Name: UNS N08020 Globe Valve, Nickel Alloy 20, 1 Inch, 800 LB
Brand: www.bossealvalves.com
SKU: 1GL8SAL20
Price: 0.01 USD
Availability: InStock
Rating: 4 (1 reviews)

Model Number: 1GL8SAL20

Key Specifications / Features

Shop high-quality 1-inch forged globe valves from a leading manufacturer. This Class 800 LB valve features DN25 size, API 602 and ASME B16.34 compliance. Crafted from UNS N08020 (Nickel Alloy 20), it boasts a bolted bonnet design and OS & Y configuration. Experience smooth flow with its regular bore.

Bolted Bonnet Globe Valve Forged Steel Globe Valve API 602 Globe Valve 1 Inch Globe Valve ASME B16.34 Globe Valve Class 800 LB Globe Valve DN25 Globe Valve SW Globe Valve

Contact Supplier

Detail Information

ALLOY 20 Globe Valve, API 602, 1 inch, 800 LB, SW + extended Bonnet, Handwheel Operated, N08020/2.4660/CN7M

Valve Description:
1873003 API 602 Forged Globe Valve 1GL8SAL20
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 1 Inch
Nominal class: 800 LB
Bore: Regular Bore
End Connection: SW-Integral extended bonnet
Operation: Handwheel
Body Material: UNS N08020, Nickel Alloy 20, 2.4660
Trim Material: UNS N08020, Nickel Alloy 20, 2.4660
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid disc, Adjustable Packing Gland, plug disc (parabola disc available)

Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: Class 800-2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: Handwheel
