Side Entry Trunnion Ball Valve, 8 Inch, 300 LB, LCB, API 6D

Name: Side Entry Trunnion Ball Valve, 8 Inch, 300 LB, LCB, API 6D
Brand: www.bossealvalves.com
SKU: 8BS3RLCB
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 8BS3RLCB

Key Specifications / Features

This 8-inch 300 LB Trunnion Mounted Ball Valve is designed for low-temperature applications and adheres to API 6D standards. Featuring a flanged connection, LCB body, 17-4PH stem, and F316 ball & seat with DEVLON seat material, this valve also includes gear operation and Nace MR0175 compliance.

API 6D Ball Valve Full Bore Ball Valve Side Entry Ball Valve Fire Safe Ball Valve Trunnion Ball Valve Class 300 LB Ball Valve 2PCS Ball Valve RF Ball Valve 8 Inch Ball Valve ASTM A352 LCB Ball Valve DN200 Ball Valve PN50 Ball Valve

Detail Information

8 Inch 300 LB Trunnion Mounted Ball Valve for Low Temperature, API 6D, Flanged, LCB Body, 17-4PH stem, F316 ball & seat, DEVLON seat, Gear Operation, Nace MR0175

Valve Description:
1811026 Trunnion Mounted Ball Valve 8BS3RLCB
Design Standard: API 6D
Structure: Two pieces casting body, Side Entry, Bolted Bonnet, Soft Seat
Nominal size: 8 Inch
Nominal class: 300 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Gear Box
Body Material: ASTM A352 LCB
Trim Material: ASTM A182 F316, DEVLON
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: Double Block & Bleed (DBB), Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN15 - DN1200)
Pressure range: Class 150 - 900 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
