RPTFE Seated Butterfly Valve, A351 CF8M, 2 IN, CL 150 LB

High-Performance Butterfly Valve, 2 Inch/DN50, 150 LB, Soft Seat, Lever Operation.

Valve Description

1862159 High-Performance Butterfly Valve
Design Standard: EN 593, API 609 Category B
Structure: Double Offset, Double Eccentric
Nominal Size: 2 Inch, DN50
Nominal Class: Class 150 LB, PN16
Seat Type: Soft Seat
Operation: Lever
Body Material: ASTM A351 CF8M, Titanium, ASTM A216 WCB, ASTM A890 4A, ASTM B148 C95800, ASTM A890 5A, ASTM A351 CF8.
Seat: RPTFE, PPL
End Connection: Wafer
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.

Product Range

Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium
Normal Diameter: 1/2-48 Inch (DN15 - DN1200)
Pressure Range: Class 150-300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged

Introduction of Double Eccentric Butterfly Valve

Compared to other valve types, double eccentric butterfly valves offer clear advantages in cost and space efficiency, with a broader size range. They provide faster operation, less restriction, and minimal wear between the disc and seat sealing surface, ensuring a longer service life and reduced total cost of ownership. The two offset design allows for lower torque and extended cycling life, making it ideal for frequent operation. Bosseal's high-performance butterfly valves have passed a million-cycle test, ensuring durability.
