Pressure Seal Bonnet Y Globe Valve, ASTM A105N, 2 IN, CL4500
Model Number: 1852064
Key Specifications / Features
As a leading exporter of Pressure Seal Bonnet Globe Valves from China, we offer a top-quality Y-Type valve made from forged steel ASTM A105N. This 2-inch valve, rated at Class 4500, adheres to API 602 and ASME B16.34 standards, ensuring high performance and reliability. It features a rising stem with handwheel for precise control and easy operation. The pressure seal bonnet design enhances sealing integrity and minimizes leakage. The valve’s angled flow path is engineered to reduce turbulence and pressure drop, resulting in more efficient flow control. This robust construction makes it ideal for high-pressure and high-temperature applications, providing dependable performance and long-lasting durability in demanding environments.
Detail Information
API 602 Y Globe Valve, Pressure Seal Bonnet, 2 Inch, 4500 LB, ASTM A105N Body, BW End.
Valve Description:
1852064 Globe Valve
Design Standard: API 602, ASME B16.34
Nominal Size: 2 Inch, DN50
Nominal Class: ANSI 4500 LB
Body Material: ASTM A105N, ASTM A182 F22, ASTM A182 F91, ASTM A182 F11, ASTM A182 F316
Bore Type: Reduced
Flow Path: The angled flow path reduces turbulence and pressure drop, leading to more efficient flow control.
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Operation: Handwheel
Structure: Pressure Seal Bonnet, Bolted Bonnet, Welded Bonnet, Bonnetless
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Face to Face: MFG'S
Applications: Chemical Processing, Water Treatment Plants, Oil and Gas Industry, HVAC Systems.
Test and Inspection: API 598
Actuation: Can be operated manually with a handwheel or automatically with an actuator, depending on the application needs.
Key Features:
Rising Stem with Handwheel: Provides precise control and easy operation.
Interchangeable Discs: Options include swivel, plug, or needle disc for versatile functionality.
Y-Pattern Design: Enhances flow efficiency and minimizes pressure drop.
OS&Y Configuration: Outside Screw & Yoke design ensures reliable performance and easy maintenance.
Live Load Packing: Offers superior sealing and reduces maintenance needs.
Backseat Feature: Enhances safety and reliability by providing additional protection.
Compact and Robust Construction: Designed to withstand high temperatures and pressures, ensuring durability in demanding environments.
Product Line:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 - 4500 LB
End Connection: BW/SW/NPT
Working Temperature: -29°C - +525°C
Operation: Manual or Actuated
Valve Description:
1852064 Globe Valve
Design Standard: API 602, ASME B16.34
Nominal Size: 2 Inch, DN50
Nominal Class: ANSI 4500 LB
Body Material: ASTM A105N, ASTM A182 F22, ASTM A182 F91, ASTM A182 F11, ASTM A182 F316
Bore Type: Reduced
Flow Path: The angled flow path reduces turbulence and pressure drop, leading to more efficient flow control.
End Connection: BW(Butt Weld), SW(Socket Weld), NPT(National Pipe Thread)
Operation: Handwheel
Structure: Pressure Seal Bonnet, Bolted Bonnet, Welded Bonnet, Bonnetless
Trim Material: ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316
Face to Face: MFG'S
Applications: Chemical Processing, Water Treatment Plants, Oil and Gas Industry, HVAC Systems.
Test and Inspection: API 598
Actuation: Can be operated manually with a handwheel or automatically with an actuator, depending on the application needs.
Key Features:
Rising Stem with Handwheel: Provides precise control and easy operation.
Interchangeable Discs: Options include swivel, plug, or needle disc for versatile functionality.
Y-Pattern Design: Enhances flow efficiency and minimizes pressure drop.
OS&Y Configuration: Outside Screw & Yoke design ensures reliable performance and easy maintenance.
Live Load Packing: Offers superior sealing and reduces maintenance needs.
Backseat Feature: Enhances safety and reliability by providing additional protection.
Compact and Robust Construction: Designed to withstand high temperatures and pressures, ensuring durability in demanding environments.
Product Line:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1/2 Inch - 2 Inch (DN15-DN50)
Pressure Range: Class 800 - 4500 LB
End Connection: BW/SW/NPT
Working Temperature: -29°C - +525°C
Operation: Manual or Actuated
