Pressure Seal Bonnet Gate Valve, C95800, 14 IN, 150 LB, OS&Y
Key Specifications / Features
We are a trusted supplier of pressure seal bonnet gate valves, engineered to API 600 standards for reliable performance in demanding applications. This 14-inch valve features a corrosion-resistant aluminum bronze body made from ASTM B148 C95800, making it ideal for seawater, marine, and industrial environments. With a Class 150 LB pressure rating, it includes an OS\&Y design for visible stem position and enhanced operational safety. The valve comes with raised face (RF) flanged ends for secure installation and offers both handwheel and gear operation options for precise and flexible flow control.
Detail Information
Valve Description:
187304009 Aluminium Bronze Gate Valve
Design Standard: API 600
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 14 Inch
Nominal Class: Class 150 LB, Class 300 LB
Bore Type: Standard Bore(API 600)
End Connection: FF or RF Flanged
Operation: Handwheel/Gear
Body Material: ASTM B148 C95800
Trim Material: ASTM B148 C95800
Face to Face: ASME B16.10
Test and Inspection: API 598
Key Features: OS&Y, Screwed-in Back seat, Rising Stem, Non-rising Handwheel, Flexible Wedge, Low Emission Design, Aluminium bronze for sea water service
Product Range:
Body Material: Aluminum Bronze
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - Class 300 LB
End Connection: RF, FF
Working Temperature: -29°C - +200°C
Operation: Handwheel/Gear/Motor
