Pressure Seal Bonnet Gate Valve, A216 WCB, 14 IN, 1500 LB
Model Number: 1821135
Key Specifications / Features
As a leading ASTM A216 WCB wedge gate valve manufacturer from China, we offer high-performance valves built for demanding applications. Our 14-inch (DN350) gate valve, crafted from carbon steel ASTM A216 WCB with Trim 8, is designed for strength and durability. Rated for 1500 LB pressure, it features an OS&Y configuration, a rising stem for easy operation, and RTJ flanged ends for secure sealing. Engineered for reliability in industrial environments, our wedge gate valves ensure long-lasting performance and optimal safety under high-pressure conditions.
Detail Information
API 600 Gate Valve, OS&Y, ASTM A216 WCB Body, Trim 8, 14 Inch/DN350, Class 1500 LB, RTJ Flanged, Rising Stem.
2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.
Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld).
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
Valve Description
A gate valve is a multi-turn isolation valve used for fully opening or closing pipelines. It operates by moving a gate between durable metal seats with hard-facing or soft seats for specific applications like water. Compact in design, gate valves prevent water hammer with their slow operation and are ideal for low pressure drop and free bore. They are commonly used with fluids like water, oil, steam, gas, and slurry.| 1821135 Gate Valve | |
| Design Standard: | API 600 |
| Structure: | Bolted Bonnet/Pressure Seal Bonnet |
| Body Material: | ASTM A216 WCB, ASTM A352 LCB, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, ASTM A890 4A, ASTM A890 5A. |
| Nominal Size: | 14 Inch, DN350 |
| Nominal Class: | 1500 LB, PN250 |
| Face to Face: | ASME B16.10 |
| Trim Material: | ASTM A182 F6A, ASTM A182 F304, ASTM A182 F316, ASTM A182 F51, ASTM A182 F53, ASTM A182 F55. |
| Bore Type: | Standard Bore(API 600) |
| Operation: | Handwheel/Gear |
| Test and Inspection: | API 598 |
| End Connection: | RTJ Flanged |
Key Features
1. OS&Y (Outside Screw and Yoke) design for reliable operation.2. Screwed-in back seat enhances security.
3. Rising stem with non-rising handwheel for ease of use.
4. Flexible wedge provides superior sealing performance.
5. Low emission design ensures environmental compliance.
Product Range
Body Material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum Bronze.Normal Diameter: 2 Inch - 64 Inch (DN50 - DN1600)
Pressure Range: Class 150 LB - 2500 LB
End Connections: RF (Raised Face), RTJ (Ring-Type Joint), BW (Butt Weld).
Working Temperature: -29°C - +400°C
Operation: Handwheel/Gear/Motor
