NACE MR0175 Gate Valve, API 600, 2 Inch, 150 LB, WCB, RF
Key Specifications / Features
This 2-inch gate valve is designed to meet API 600 standards and features an OS & Y design, RF flanges, and WCB body construction. The 1Cr13 trim and handwheel make it easy to operate, while NACE compliance ensures it is suitable for use in harsh environments. Perfect for use in the oil and gas industry.
Request a quote
Detail Information
2 Inch Class 150 Flanged Gate Valve, API 600, OS & Y, RF, WCB Body, 1Cr13 Trim, Handwheel, NACE
Valve Description:
1821014 Gate Valve 2G1RWCB08
Design Standard: API 600
Structure: Bolted Bonnet
Nominal size: 2 Inch
Nominal class: 150 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: Handwheel
Body Material: ASTM A216 WCB
Trim Material: 1Cr13+STL, No.8
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Flexible Wedge, OS & Y, Non-rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, NACE MR0175
Product Range:
Body material: Carbon Steel
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +350℃
Operation: Handwheel, Gear, Motor Actuator
Valve Description:
1821014 Gate Valve 2G1RWCB08
Design Standard: API 600
Structure: Bolted Bonnet
Nominal size: 2 Inch
Nominal class: 150 LB
Bore Type: Standard Bore
End Connection: RF (Raised Face)
Operation: Handwheel
Body Material: ASTM A216 WCB
Trim Material: 1Cr13+STL, No.8
Face to face: ASME B16.10
Test and inspection: API 598
Key Features: Flexible Wedge, OS & Y, Non-rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, NACE MR0175
Product Range:
Body material: Carbon Steel
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW
Working temperature: -29℃ - +350℃
Operation: Handwheel, Gear, Motor Actuator
