Modular Double Block & Bleed Ball Valve, 6 IN, 1500 LB, RTJ

Name: Modular Double Block & Bleed Ball Valve, 6 IN, 1500 LB, RTJ
Brand: www.bossealvalves.com
SKU: 6DBB15JLF2
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 6DBB15JLF2

Key Specifications / Features

We Provide Modular Double Block and Bleed Ball Valves, DBB, 6 Inch, 1500 LB, Full Bore, RTJ End, ASTM A350 LF2, API 6D, Gear Operation, DN150, and PN250.

API 6D Ball Valve Full Bore Ball Valve DBB Ball Valve ASTM A350 LF2 Ball Valve Double Block and Bleed Ball Valve Modular Double Block Valves Class 1500 LB Ball Valve RTJ Ball Valve PN250 Ball Valve DN150 Ball Valve

Detail Information

Product Item: Modular Double Block and Bleed Ball Valve
Model No.: 6DBB15JLF2
Design Standard: API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, Soft Seat, Double Ball, Compact body
Nominal size: 6 Inch
Nominal class: 1500 LB
Bore Type: Full Bore
End Connection: RTJ
Operation: Gear
Body Material: ASTM A350 LF2
Trim Material: ASTM A182 F316, PEEK
Face-to-face: Manufacturer Standard
Test and inspection: API 598, API 6D
Key Features: Double Ball, Double Block&Bleed(DBB), Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection, O-ring / Lip seal
configuration available, Low fugitive emission stem packing available

Product Range
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 24 Inch (DN15 - DN600)
Pressure range: 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +150℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
