Metal Seated Ball Valve, ASTM A350 LF2, 16 Inch, 300 LB, RF

Name: Metal Seated Ball Valve, ASTM A350 LF2, 16 Inch, 300 LB, RF
Brand: www.bossealvalves.com
SKU: 16BSM3RLF2
Price: 0.01 USD
Availability: InStock
Rating: 4 (1 reviews)

Model Number: 16BSM3RLF2

Key Specifications / Features

Looking for a high-quality metal-seated trunnion-mounted ball valve? Look no further than our API 6D-compliant valve with a 16-inch size, 300 LB rating, RF connection, LF2 body, and metal seat. Designed for optimal performance and durability, this valve is perfect for demanding applications. Featuring gear operation, it is easy to operate and maintain. Trust us for all your valve needs!

API 6D Ball Valve 16 Inch Ball Valve Three Pieces Ball Valve Side Entry Ball Valve Bolted Bonnet Ball Valve ASTM A350 LF2 Ball Valve Class 300 LB Ball Valve RF Ball Valve

Contact Supplier

Detail Information

Metal Seated Trunnion Mounted Ball Valve, API 6D, 16 inch, 300 LB, RF, LF2 Body, metal seat, Gear Operation

Valve Description:
1811027 Trunnion Mounted Ball Valve 16BSM3RLF2
Design Standard: API 6D
Structure: Three pieces forged body, Side Entry, Bolted Bonnet, Metal Seat
Nominal size: 16 Inch
Nominal class: 300 LB
Bore Type: Full Bore
End Connection: RF Flanged
Operation: Gear Box
Body Material: ASTM A350 LF2
Trim Material: Ball-A182 F304 + Hard Chrome, Seat-A182 F316 + Stellite 12
Face to face: ASME B16.10
Test and inspection: API 598, API 6D
Key Features: Double Block & Bleed (DBB), Anti-static Device, Fire Safe, Anti-Blowout Stem, Emergency sealant injection, Metal seat

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 48 Inch (DN15 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: RF, RTJ, BW, HUB
Working temperature: -46℃ - +350℃
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
