High Performance Butterfly Valve, ASTM A216 WCB, 32IN, 150 LB
Model Number: 1862133
Key Specifications / Features
As a high-performance butterfly valve manufacturer, we offer valves that meet API 609, Category B, and EN 593 standards. Our 32-inch, CL 150 LB valves feature a double offset design and are equipped with an RPTFE seat for superior sealing. The robust 17-4PH stem ensures durability and reliability, while the double flanged ends provide secure installation. Engineered for exceptional performance in demanding industrial environments, our valves deliver precision control and long-lasting service. As a leading butterfly valve manufacturer in China, we are dedicated to providing top-quality solutions.
Detail Information
RPTFE Seated Butterfly Valve, Double Offset, 32 Inch/DN800, Class 150 LB, Gear Operation.
Design Standard: API 609 Category B, EN 593
Structure: Double Offset, Double Eccentric
Body Material: ASTM A216 WCB, ASTM A890 4A, ASTM B148 C95800, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, Titanium.
Nominal Size: 32 Inch, DN800
Nominal Class: Class 150 LB, PN20
Seat Type: Soft Seat
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Double Flanged
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
Valve Description
1862133 High-Performance Butterfly ValveDesign Standard: API 609 Category B, EN 593
Structure: Double Offset, Double Eccentric
Body Material: ASTM A216 WCB, ASTM A890 4A, ASTM B148 C95800, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, Titanium.
Nominal Size: 32 Inch, DN800
Nominal Class: Class 150 LB, PN20
Seat Type: Soft Seat
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Double Flanged
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire safe seat available.
Product Range
Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, TitaniumOperation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Working Temperature: -26°C - +120°C (180°C for PPL seat)
End Connection: Wafer, Lug, Flanged
Double Eccentric Butterfly Valve Introduction
The double eccentric butterfly valve stands out for its cost and space efficiency, offering a larger size range compared to other valve types. Its design allows for faster operation and minimizes restrictions and wear between the disc and seat sealing surface. This results in a longer service life and reduced total cost of ownership. The two offsets in the valve contribute to its durability and lower torque requirements, making it ideal for frequent operation. The Bosseal high-performance butterfly valve has successfully passed a million-cycle test, demonstrating its exceptional reliability and longevity.
Different End Connections Available
