Forged Y Globe Valve, 3/4IN, A105N, 1500 LB, Trim 5, SW

Name: Forged Y Globe Valve, 3/4IN, A105N, 1500 LB, Trim 5, SW
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

Looking for a reliable Y Pattern Globe Valve Supplier? We offer high-quality valves meeting API 602 and ASME B16.34 standards. Our 3/4-inch valve is rated at Class 1500 LB, with DN20 and PN250 specifications. Crafted from ASTM A105N material, it features a bolted bonnet, SW end connection, and easy handwheel operation.

Request a quote

Detail Information

1500 LB Forged Y Pattern Globe Valve, API 602, 3/4 INCH, 1500 LB, SW End, A105 Body, Trim 5, Handwheel

Valve Description:
1852017 API 602 Forged Globe Valve 0.75GL8SA10505
Design Standard: API 602, ASME B16.34
Structure: Bolted Bonnet, OS & Y
Nominal size: 3/4 Inch
Nominal class: 1500 LB
Bore: Regular Bore
End Connection: SW
Operation: Handwheel
Body Material: ASTM A105N
Trim Material: F6A+STL, No.5
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Independent backseat, Fully guided solid disc, Adjustable Packing Gland, plug disc (parabola disc available)

Product Range:
Body material: Carbon Steel, Stainless Steel, Duplex steel, Alloy
Normal diameter: 1/2-2 Inch (DN15 - DN50)
Pressure range: 800LB-2500LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +400℃
Operation: Handwheel
