FNPT Threaded Ball Valve, 3/4 Inch, 1500 LB, A350 LF2

Name: FNPT Threaded Ball Valve, 3/4 Inch, 1500 LB, A350 LF2
Brand: www.bossealvalves.com
SKU: 0.75BB15NLF2
Price: 0.01 USD
Availability: InStock
Rating: 5 (1 reviews)

Model Number: 0.75BB15NLF2

Key Specifications / Features

Explore top-quality FNPT threaded floating-type ball valves from a renowned maker in a 3/4-inch size, DN20, with a pressure rating of 1500 LB (PN250). Crafted from ASTM A350 LF2 material, featuring a 316 trim and compliant with ISO 17292, API 608, and API 6D standards. Equipped with RPTFE seat and lever lockable mechanism for optimal performance.

API 6D Ball Valve ASTM A350 LF2 Ball Valve API 608 Ball Valve DN20 Ball Valve ISO 17292 Ball Valve Class 1500 LB Ball Valve PN250 Ball Valve 3/4 Inch Ball Valve FNPT Ball Valve

Detail Information

3/4 inch, 1500 LB, Floating Ball Valve, FNPT Threaded End, ISO 17292, LF2 body with 316 Trim, RPTFE seat and lever operation

Valve Description:
1812033 Floating Ball Valve 0.75BB15NLF2
Design Standard: API 608, ISO 17292, API 6D
Structure: Three pieces body, Side Entry, Bolted Bonnet, Soft Seat
Nominal size: 3/4 Inch, DN20
Nominal class: 1500 LB
Bore Type: Full Bore
End Connection: FNPT
Operation: Lever Lockable
Body Material: ASTM A350 LF2
Trim Material: ASTM A182 F316, RPTFE
Face to face: Manufacturer Standard
Test and inspection: API 598
Key Features: Anti-static Device, Fire Safe, Anti-Blowout Stem, Locking Device

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 1/2 - 2 Inch (DN15 - DN50)
Pressure range: Class 150 - 2500 LB
End connection: SW, NPT, BSP
Working temperature: -29℃ - +150℃
Operation: Lever, Spring Return Lever, Pneumatic Actuator
