EN 593 Wafer Butterfly Valve, Titanium, CL 300, 14 Inches
Model Number: 1862188
Key Specifications / Features
As a fabricator of 17-4PH stem butterfly valves, we produce high-performance valves designed to meet EN 593 and API 609 Category B standards. Our 14-inch (DN350) butterfly valve features a double offset design for enhanced reliability and precision. Constructed from titanium for superior strength and corrosion resistance, this valve is rated for 300 LB and PN50, making it ideal for demanding applications. The wafer end connection allows for easy installation, ensuring efficient performance in a variety of industrial environments where durability and high performance are critical.
Detail Information
EN 593 Double Offset Butterfly Valve, High-Performance, 14 Inches, 300 LB, 17-4PH Stem.
Design Standard: EN 593, API 609 Category B
Nominal Size: 14 Inch, DN350
Nominal Class: Class 300 LBS, PN50
Seat Type: Soft Seat
Operation: Gear
Body Material: Titanium, ASTM A216 WCB, ASTM A890 5A, ASTM A890 4A, ASTM A351 CF8M, ASTM A351 CF8, ASTM B148 C95800.
Seat: RPTFE, PPL
End Connection: Wafer
Structure: Double Offset, Double Eccentric
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire-safe seat available.
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C to +120°C (180°C for PPL seat)
Valve Description
1862188 High-Performance Butterfly ValveDesign Standard: EN 593, API 609 Category B
Nominal Size: 14 Inch, DN350
Nominal Class: Class 300 LBS, PN50
Seat Type: Soft Seat
Operation: Gear
Body Material: Titanium, ASTM A216 WCB, ASTM A890 5A, ASTM A890 4A, ASTM A351 CF8M, ASTM A351 CF8, ASTM B148 C95800.
Seat: RPTFE, PPL
End Connection: Wafer
Structure: Double Offset, Double Eccentric
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replaceable seat, Tight sealing, Excellent control characteristics, Bi-direction sealing under full pressure, fire-safe seat available.
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Product Range
Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, TitaniumNormal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C to +120°C (180°C for PPL seat)
