EN 593 Butterfly Valve, ASTM A351 CF8, CL 300, 10 Inch, Lug
Model Number: 1862228
Key Specifications / Features
As a leading fabricator of butterfly valves, we offer high-performance solutions featuring a 17-4PH stem. Our valves are designed with a double offset configuration and meet EN 593 and API 609 Category B standards. Constructed with a CF8 body, these 10-inch (DN250) valves are rated at 300 LB and PN50, and come with lug ends for easy installation. Engineered for exceptional performance and durability, they are ideal for demanding industrial applications requiring robust and reliable operation.
Detail Information
EN 593 High-Performance Butterfly Valve, Double Offset, 10 Inches/DN250, 300 LB, 17-4PH Stem.
Design Standard: EN 593, API 609 Category B
Nominal Size: 10 Inch, DN250
Nominal Class: Class 300 LBS, PN50
Seat Type: Soft Seat
Operation: Gear
Body Material: ASTM A351 CF8, Titanium, ASTM A216 WCB, ASTM A890 5A, ASTM A890 4A, ASTM A351 CF8M, ASTM B148 C95800.
Seat: RPTFE, PPL
End Connection: Lug
Structure: Double Offset, Double Eccentric
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replacement seat, Tight sealing, Excellent control characteristics, Bi-directional sealing under full pressure, fire-safe seat available.
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Normal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C to +120°C (180°C for PPL seat)
Valve Description
1862228 High-Performance Butterfly ValveDesign Standard: EN 593, API 609 Category B
Nominal Size: 10 Inch, DN250
Nominal Class: Class 300 LBS, PN50
Seat Type: Soft Seat
Operation: Gear
Body Material: ASTM A351 CF8, Titanium, ASTM A216 WCB, ASTM A890 5A, ASTM A890 4A, ASTM A351 CF8M, ASTM B148 C95800.
Seat: RPTFE, PPL
End Connection: Lug
Structure: Double Offset, Double Eccentric
Key Features: Long working life for frequent operation (million cyclings), Lower torque, Replacement seat, Tight sealing, Excellent control characteristics, Bi-directional sealing under full pressure, fire-safe seat available.
Face to Face: API 609, EN 593
Test and Inspection: API 598, API 609
Trim Material: ASTM A351 CF8, ASTM A351 CF8M, ASTM A890 4A, ASTM A890 5A, ASTM B148 C95800, Titanium
Product Range
Body Material: Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, TitaniumNormal Diameter: 1/2 Inch - 48 Inch (DN15 - DN1200)
Pressure Range: Class 150 LB - 300 LB
Operation: Manual (lever, gear), Pneumatic Actuator, Motor Actuator
End Connection: Wafer, Lug, Flanged
Working Temperature: -26°C to +120°C (180°C for PPL seat)
