Duplex Stainless Steel Check Valve, A995 6A, 8 Inch, 150 LB

Name: Duplex Stainless Steel Check Valve, A995 6A, 8 Inch, 150 LB
Brand: www.bossealvalves.com
SKU: 8SBN1L6A
Price: 0.01 USD
Availability: InStock
Rating: 4 (1 reviews)

Model Number: 8SBN1L6A

Key Specifications / Features

This Metal Seat Super Duplex Stainless Steel Dual Plate Check Valve is constructed with A995 6A/S32760/F55/1.4501/CD3MWCuN, meets API 594 standards, and features an 8-inch size, 1500 LB pressure rating, and lug end. The valve also includes an integral+STL seat for reliable performance.

Class 150 LB Check Valve API 594 Check Valve RF Check Valve PN20 Check Valve ASTM A995 6A Check Valve 8 Inch Check Valve DN200 Check Valve Lug Check Valve API 6D Check Valve Duplex Stainless Steel Check Valve

Contact Supplier

Detail Information

Metal Seat Super Duplex Stainless Steel Dual Plate Check Valve, A995 6A/S32760/F55/1.4501/CD3MWCuN, API 594, 8 Inch, 1500 LB, Lug End, Integral+STL Seat

Valve Description:
1842007 Dual Plate Check Valve 8SBN1L6A
Design Standard: API 594, API 6D
Structure: Dual Plate spring return
Nominal size: 8 Inch
Nominal class: 150 LB
End Connection: LUG-RF
Operation: /
Body Material: ASTM A995 6A
Trim Material: A995 6A disc, X-750 Spring, INT+STL seat
Face to face: API 594
Test and inspection: API 598
Key Features: Retainerless Design, High flow efficiency, Low noise, Short face-to-face length, High Anti-corrosion material, seawater service

Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel, Aluminum bronze, Ti
Normal diameter: 2 - 48 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB
End connection: Wafer, Lug, Flanged, HUB
Working temperature: -29℃ - +400℃
Operation: /
