Class 200 LB Bronze Gate Valves, MSS SP-80, 3/8 IN, C83600
Model Number: 1876022
Key Specifications / Features
As a reliable ASTM B62 C83600 bronze gate valve supplier in China, we offer valves designed to MSS SP-80 standards for dependable performance. Our 3/8 inch (DN10) gate valves are rated for Class 200 LB and feature a threaded bonnet and non-rising stem for compact, efficient operation. With a standard bore design, these valves provide reliable flow control in a variety of industrial applications. Built from high-quality bronze, our gate valves ensure long-lasting durability and performance in demanding environments.
Detail Information
MSS SP-80 Bronze Gate Valves, ASTM B62 C83600, 3/8 Inch, Class 200 LB, Threaded Bonnet.
Valve Description:
Key Features:
1. Renewable solid wedges for enhanced durability.
2. Integral seats for improved sealing performance.
3. High-tensile bronze alloy stems for strength and reliability.
4. Each valve undergoes shell and seat pressure testing under MSS SP-80 industry standards.
5. Options for both rising and non-rising stems are available.
Product Range:
Body Material: Bronze ASTM B62 C83600
Normal Diameter: 1/4 Inch - 3 Inch (DN6 – DN80)
Pressure Range: Class 125 LBs, 150 LBs, 200 LBs, 300 LBs
Working Temperature: -20°C to +150°C
End Connection: Threaded
Operation: Handwheel
Valve Description:
| 1876022 Gate Valve | |
| Bore Type: | Standard Bore |
| Structure: | Threaded, Union Bonnet |
| Design Standard: | MSS SP-80 |
| Size Range: | 3/8 Inch, DN10 |
| Class Rating: | Class 200 LB |
| Body Material: | ASTM B62 C83600 |
| Test and Inspection: | MSS SP-80 |
| Trim Material: | ASTM B62 C83600 |
| Face to Face: | Manufacturer Standard |
| End Connection: | Threaded ASME B1.20.1 |
| Operation: | Handwheel |
Key Features:
1. Renewable solid wedges for enhanced durability.
2. Integral seats for improved sealing performance.
3. High-tensile bronze alloy stems for strength and reliability.
4. Each valve undergoes shell and seat pressure testing under MSS SP-80 industry standards.
5. Options for both rising and non-rising stems are available.
Product Range:
Body Material: Bronze ASTM B62 C83600
Normal Diameter: 1/4 Inch - 3 Inch (DN6 – DN80)
Pressure Range: Class 125 LBs, 150 LBs, 200 LBs, 300 LBs
Working Temperature: -20°C to +150°C
End Connection: Threaded
Operation: Handwheel
