Class 150 LB Bronze Gate Valve, MSS SP-80, 1/4 IN, C83600
Key Specifications / Features
As a leading supplier of ASTM B62 C83600 Bronze Gate Valves in China, we offer a premium product designed to meet MSS SP-80 standards. This 1/4-inch valve features a DN6 size and a Class 150 LB rating, making it suitable for a variety of applications. It is equipped with a threaded bonnet for easy installation and maintenance, along with a non-rising stem design that saves space. The standard bore design ensures optimal flow efficiency, providing a reliable solution for industries requiring high-quality performance in compact settings.
Request a quote
Detail Information
MSS SP-80 Bronze Gate Valve, ASTM B62 C83600, 1/4 Inch, Class 150 LB, Threaded Bonnet.
Valve Description:
Key Features:
1. Renewable solid wedges for enhanced durability.
2. Integral seats for improved sealing performance.
3. High-tensile bronze alloy stems for strength and reliability.
4. Each valve undergoes shell and seat pressure testing in accordance with MSS SP-80 industry standards.
5. Options for both rising and non-rising stems are available.
Product Range:
Body Material: Bronze ASTM B62 C83600
Normal Diameter: 1/4 Inch - 3 Inch (DN6 – DN80)
Pressure Range: Class 125 LB - 300 LB
Working Temperature: -20°C to +150°C
End Connection: Threaded
Operation: Handwheel
Valve Description:
| 1876011 Gate Valve | |
| Bore Type: | Standard Bore |
| Structure: | Threaded, Union Bonnet |
| Design Standard: | MSS SP-80 |
| Size Range: | 1/4 Inches, DN6 |
| Class Rating: | Class 125 LB |
| Body Material: | ASTM B62 C83600 |
| Test and Inspection: | MSS SP-80 |
| Trim Material: | ASTM B62 C83600 |
| Face to Face: | Manufacturer Standard |
| End Connection: | Threaded ASME B1.20.1 |
| Operation: | Handwheel |
Key Features:
1. Renewable solid wedges for enhanced durability.
2. Integral seats for improved sealing performance.
3. High-tensile bronze alloy stems for strength and reliability.
4. Each valve undergoes shell and seat pressure testing in accordance with MSS SP-80 industry standards.
5. Options for both rising and non-rising stems are available.
Product Range:
Body Material: Bronze ASTM B62 C83600
Normal Diameter: 1/4 Inch - 3 Inch (DN6 – DN80)
Pressure Range: Class 125 LB - 300 LB
Working Temperature: -20°C to +150°C
End Connection: Threaded
Operation: Handwheel
