ASTM B62 C83600 Gate Valves, MSS SP-80, 1 IN, CL300, NPT

Name: ASTM B62 C83600 Gate Valves, MSS SP-80, 1 IN, CL300, NPT
SKU: 1876024
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a trusted supplier of non-rising stem bronze gate valves from China, we offer valves built to MSS SP-80 standards with durable ASTM B62 C83600 bronze bodies. Our 1-inch (DN25) valves are rated for Class 300 LB and feature a threaded bonnet for secure connections and easy maintenance. Designed with a handwheel for smooth and precise operation, these valves provide excellent flow control in various industrial settings, ensuring reliable performance and long service life.

Request a quote

Detail Information

ASTM B62 C83600 Gate Valves, MSS SP-80, 1 Inch, DN25, 300 LB, Threaded Bonnet.

Valve Description:
1876024 Gate Valve
Design Standard: MSS SP-80
Nominal Size: 1 Inch, DN25
Nominal Class: Class 300 LB, PN50
Body Material: ASTM B62 C83600
Bore Type: Standard Bore
Structure: NPT Threaded, Union Bonnet
Operation: Handwheel
Trim Material: ASTM B62 C83600
End Connection: Threaded ASME B1.20.1
Face to Face: Manufacturer Standard
Test and Inspection: MSS SP-80

Key Features:
1. Renewable solid wedges for enhanced durability.
2. Integral seats for improved sealing performance.
3. High-tensile bronze alloy stems for strength and reliability.
4. Each valve undergoes shell and seat pressure testing under MSS SP-80 industry standards.
5. Options for both rising and non-rising stems are available.

Product Range:

Body Material:	Bronze ASTM B62 C83600
Normal Diameter:	1/4, 3/8, 1/2, 3/4, 1, 1-1/2, 2, 2-1/2, 3 Inch (DN6 – DN80)
Pressure Range:	Class 125, 150, 200, 300 LB
End Connection:	NPT Threaded
Working Temperature:	-20°C - +150°C
Operation:	Handwheel
