ASTM B148 C95800 Butterfly Valve, 36 Inch, 150 LB, API 609

Looking for a reliable and durable valve for your industrial application? Check out our Aluminum Bronze ASTM B148 C95800 Triple Offset Butterfly Valve! This high-quality valve is designed to meet API 609 standards and features a 36 inch (DN900) size, 150 LB rating, double flange connection, and gear operation. With its advanced triple offset design and premium aluminum bronze construction, this valve provides reliable and precise control over your process fluids. Contact us today to learn more about this top-of-the-line valve and how it can benefit your business.

Aluminum bronze ASTM B148 C95800 Triple Offset Butterfly Valve,  API 609, 36Inch(DN900), 150LB, Double Flange, Gear Operation

Valve Description：
1873004 Triple Offset Butterfly Valve 36TC1RC958
Design Standard: API 609 Cat B, EN593
Structure: Triple Offset
Nominal size: 36 Inch
Nominal class: 150LB
End Connection: Double Flange
Operation: Gear
Body Material: ASTM B148 C95800
Trim Material: B148 C95800 disc, F51+PTFE disc seat
Face to face: API 609
Test and inspection: API 598
Key Features: Metal Seat for High Temperature and various fluids, Low torque, Replaceable seat, Zero Leakage,Excellent control characteristics,
Suitable for offshore sea water service.

Product Range：
Body material: WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: 150 - 2500 LB
End connection: Wafer, Lug, Flanged, BW
Working temperature: -29℃ - +400℃
Operation: Lever, Gear, Motor, Pneumatic Actuated
