ASTM B148 C95800 Butterfly Valve, 26IN, CL150, API 609
Model Number: 1862382
Key Specifications / Features
As a leading provider of API 609 Category B butterfly valves in China, we offer high-performance 26-inch valves made from ASTM B148 C95800. Designed to EN 593 standards, these double eccentric valves feature a Monel K500 stem and an RPTFE seat, rated for Class 150 LB with flanged ends. Compared to other valve types, they provide significant cost and space savings, a wider size range, and faster operation. With reduced wear between the disc and seat, these valves ensure a longer service life and help lower the total cost of ownership.
Detail Information
Double Eccentric Butterfly Valve, 26 Inch, 150 LB, ASTM B148 C95800 Body, RPTFE Seated.
Design Standard: API 609 Category B, EN 593
Body Material: ASTM B148 C95800, ASTM A351 CF8M, ASTM A890 4A, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 5A, Titanium.
Nominal Size: 26 Inch, DN650
Structure: Double Offset, Double Eccentric
Nominal Class: 150 LBS
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Double Flanged
Test and Inspection: API 598, API 609
Trim Material: ASTM A890 4A, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, Titanium.
2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.
Valve Description
1862382 High-Performance Butterfly ValveDesign Standard: API 609 Category B, EN 593
Body Material: ASTM B148 C95800, ASTM A351 CF8M, ASTM A890 4A, ASTM A216 WCB, ASTM A351 CF8, ASTM A890 5A, Titanium.
Nominal Size: 26 Inch, DN650
Structure: Double Offset, Double Eccentric
Nominal Class: 150 LBS
Seat Type: Soft Seat
Face to Face: API 609, EN 593
Operation: Gear
Seat: RPTFE, PPL
End Connection: Double Flanged
Test and Inspection: API 598, API 609
Trim Material: ASTM A890 4A, ASTM A890 5A, ASTM A351 CF8, ASTM A351 CF8M, ASTM B148 C95800, Titanium.
Key Features
1. Long lifespan for high-frequency operation (up to a million cycles).2. Reduced torque for smoother operation.
3. Replaceable seat for easy maintenance.
4. Reliable tight sealing performance.
5. Superior control characteristics.
6. Bi-directional sealing under full pressure.
7. Fire-safe seat option available.
Product Range
| Body Material: | Carbon Steel, Stainless Steel, Duplex Steel, Aluminum Bronze, Titanium Alloy |
| Normal Diameter: | 1/2 - 48 Inch (DN15 - DN1200) |
| Pressure Range: | Class 150 LB - 300 LB |
| Operation: | Manual (lever, gear), Pneumatic Actuator, Motor Actuator |
| Working Temperature: | -26°C - +120°C (180°C for PPL seat) |
| End Connection: | Wafer, Lug, Flanged(FF, RF, RTJ) |
| Top Mounting: | ISO 5211 Top Mounting Available |
Introduction to Double Eccentric Butterfly Valve
Compared to other valve types, the double eccentric butterfly valve offers significant cost and space savings, with a wider size range. Its faster operation and reduced wear between the disc and seat sealing surface ensure a longer cycling life and lower total cost of ownership. The two offsets provide extended durability, lower torque, and make the valve ideal for frequent operation. Bosseal high-performance butterfly valves have successfully passed a million-cycle test, guaranteeing reliability and long-term performance in demanding applications.
