ASTM A694 F65 Globe Valve, API 6A, ASME B16.34, 2IN, 10000 PSI, HUB
Key Specifications / Features
Explore top-quality ASTM A694 F65 globe valves from a trusted provider. Our 2-inch valves, conforming to DN50 standards, are designed for reliable performance at 10000 PSI. Compliant with BS 1873, API 6A, and ASME B16.34, these valves feature plug disc, OS & Y, renewable seat, HUB end, and convenient handwheel operation.
Request a quote
Detail Information
API 6A Globe Valve, API 6A, 2 inch, 10000 PSI, HUB End, A694 F65 Body, Handwheel Operation
Valve Description:
1831012 Globe Valve 2GLP100HF65
Design Standard: BS 1873, API 6A, ASME B16.34
Structure: Pressure Seal Bonnet, Plug Disc
Nominal size: 2 Inch
Nominal class: 10000 PSI
Bore Type: Standard Bore
End Connection: hub end
Operation: Handwheel
Body Material: ASTM A694 F65
Face to face: MFG'S
Test and inspection: API 598
Key Features: Plug Disc, OS & Y, Rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, Connival Disc available
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB, 10000PSI
End connection: RF, RTJ, BW, HUB
Working temperature: -29℃ - +400℃
Operation: Handwheel, Gear, Motor Actuator
Valve Description:
1831012 Globe Valve 2GLP100HF65
Design Standard: BS 1873, API 6A, ASME B16.34
Structure: Pressure Seal Bonnet, Plug Disc
Nominal size: 2 Inch
Nominal class: 10000 PSI
Bore Type: Standard Bore
End Connection: hub end
Operation: Handwheel
Body Material: ASTM A694 F65
Face to face: MFG'S
Test and inspection: API 598
Key Features: Plug Disc, OS & Y, Rising Handwheel, Low fugitive emission stem packing available, Renewable Seat, Connival Disc available
Product Range:
Body material: Carbon Steel, Stainless Steel, Alloy Steel
Normal diameter: 2 - 24 Inch (DN50 - DN1200)
Pressure range: Class 150 - 2500 LB, 10000PSI
End connection: RF, RTJ, BW, HUB
Working temperature: -29℃ - +400℃
Operation: Handwheel, Gear, Motor Actuator
