ASTM A694 F60 Globe Valve, API 6A, 6-3/8 IN, PSB, 17-4PH Trim

Name: ASTM A694 F60 Globe Valve, API 6A, 6-3/8 IN, PSB, 17-4PH Trim
SKU: GLV-183103033
Availability: InStock
Rating: 5 (1 reviews)

Key Specifications / Features

As a trusted China pressure seal bonnet globe valve provider, we deliver robust solutions engineered to meet API 6A standards for demanding oil and gas operations. Our 6-3/8 inch globe valves are rated for 10,000 PSI, ensuring reliable performance under extreme pressure conditions. Constructed with premium body materials such as ASTM A694 F60, F65, 4130, or Inconel, these valves offer exceptional durability and resistance to corrosion. Featuring 17-4PH stainless steel trim, RTJ or butt-weld ends, and gear operation, they guarantee precise flow control, long service life, and enhanced sealing reliability.

Request a quote

Detail Information

Valve Description:
183103033 API 6A Globe Valve
Design Standard: API 6A
Structure: Bolted Bonnet/Pressure Seal Bonnet
Nominal Size: 1-13/16 Inch to 11 Inch
Nominal Class: 2,000 PSI-15,000 PSI
Bore Type: Standard
End Connection: RTJ, BW, and Hub
Operation: Lever/Gear/Bare Shaft
Body Material: AISI 4130/ASTM A694 F60/ASTM A694 F65/Inconel
Trim Material: AISI 4140/F51/17-4PH/Inconel Trim
Seat Insert: TCC or STL Hardfaced
Face to Face: ASME B16.10/MFG'S
Test and Inspection: API 6A

Key Features:
Material Class: AA, BB, CC, DD, EE, FF, HH
Temperature Class: L, N, P, S, T, U, V, X, Y
Specification: PSL1 - PSL3G
Performance: PR1, PR2

Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel
Normal Diameter: 1-13/16 - 11 Inch
Pressure Range: 2,000 PSI - 15,000 PSI
End Connection: RF, RTJ, BW, HUB
Working Temperature: -26°C - +400°C
Operation: Manual(lever, gear), Pneumatic Actuator, Motor Actuator
