C95800 Disc Concentric Butterfly Valve, 12 inch/DN300, PN16, LUG, ASTM A536 Ductile Iron body, C95800 Disc, rubber lined seat, Gear Operation
Valve Description:
1861006 Concentric Butterfly Valve 12T1LDI
Design Standard: API 609 Cat A, EN 593
Structure: Concentric, Rubber Lined
Nominal size: 12 Inch / DN300
Nominal class: 150 LB / PN16
End Connection: LUG
Operation: Gear Operation
Body Material: ASTM A536
Trim Material: ASTM B148 C95800, NBR seat
Face to face: API 609, EN558
Test and inspection: API 598
Key Features: Super Anti-corrosive NBR seat, Low torque, Excellent control characteristics, Economical material and installation space
Product Range:
Body material: Iron, WCB, Stainless Steel, Duplex steel, Al-Bronze, Ti
Normal diameter: 2 - 72 Inch (DN50 - DN1800)
Pressure range: PN6-PN20
End connection: Wafer, Lug, Flanged
Working temperature: -29℃ - +120℃
Operation: Lever, Gear
